PMM - Power Meter Monitor

PMM0306

INDUSTRIAL ETHERNET PoE SWITCH WITH FIBER

KEY FEATURES

  • Layer 2 / Layer 3 routing functions
  • 8 Gigabit PoE ports + 2 Gigabits + 1 Console port
  • Supports: IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3z/ab, IEEE802.1Q, IEEE802.1p, IEEE802.1d/w
  • Supports PoE Power Management, PoE Watchdog based on data stream detection
  • Supports: IEEE802.3af (15.4w), IEEE802.3at (30w), IEEE802.3bt (90w)
  • Supports: STP (802.1D, RSTP (802.1w), MSTP (802.1s), ERPS
  • Supports SNMP v1/v2/v3
  • Supports IGMP Snooping , Static multicast filtering and MLD Snooping
  • Supports 802.1x port and AAA Certification, Enhance network security
  • Supports WEB, Telnet，CLI,SSH management
  • Supports lightning protection, surge: General Mode 6KV, Differential Mode2KV, ESD: 15KV
  • Supports EMC EN55032 standard
  • Built to meet all Power substation requirements
  • Wide range of power supply options
  • -40 to 85°C (-40 to 185°F) system operating temperature
  • Din rail, wall, panel and rack mount options
3 in stock
Base Price:412.56 $

Contact Sales

DESCRIPTION

PMM0306 is a low-power Industrial Ethernet Switch, certified by industrial environment and supports FCC, CE, CCC and RoHS standards; reliable industrial design ensures uninterrupted automation system stable operation.

PMM switches provide advanced network management capabilities; redundant ring, loop protection, VLAN, QOS, speed control, port mirroring and firmware online upgrades. With standardized industrial design, it can meet the stringent requirements of industrial sites, since it is covered by a durable metal chassis which was designed and tested on the field to withstand shock, vibration, extended temperature ranges and challenging elements of a harsh environment. All components use industrial grade for greater reliability, providing redundant, wide-voltage power inputs and outputs for uninterrupted industrial safety communications

APPLICATION

PMM0306 is especially designed to meet all power substations and PV plants requirements. Furthermore, it covers all field standards of power, reliability, easy configuration and long-lasting life.

Moreover, PMM0306 offers the client a wide range of interfaces covering most of the industrial standards and applications:

  • Metropolitan area fiber broadband network: telecommunications, cable TV, network system integration, etc., network operators
  • Broadband private network: Suitable for financial, government, oil, railway, electric power, public security, transportation, education and other industries
  • Multimedia transmission: image, voice, data integrated transmission, suitable for remote teaching, conference TV, videophone and other applications
